78A Top-hung Sliding Door Series

Fashionable appearance, integral design is concise and smooth. Special treatment on joint corners, it is convenient to clean.

< Previous
Next >
Back
Product Features


· Fashionable appearance, integral design is concise and smooth. Special treatment on joint corners,

it is convenient to clean.

· Extrusions are made with enough materials and have homogenous thickness. The special force position

is thickened and added with reinforced parts.

· Door sleeve covers are spliced seamlessly, it makes door style nicer and more active.

· The profiles are designed to comply with European standard hardware slot, connecting multiple locking points, achieving a good anti-theft effect.

· 9mm width of aluminum strips ensure the connection tightness and sound-insulation effect. It has multiple wind and waterproof designs with sound-proof, dust-proof and water-proof functions.

· It uses SUS304 stainless sliding tracks which can load 200KG, pulleys work 100000 times without damage.

· 5mm double-layers fully sealed automotive grade safety glass, with chemical molecular sieves and argon inflated. Double-layers ensure better sealing effect.

· Exquisite lock with smooth outlines, it feels comfortable, The beauty of aluminum alloy and retro style is combined into the handle.


product structure


Bottom sliding track.jpg

Product parameters


Frame Thickness: 108mm(double tracks),  163mm(triple tracks)

Glass Thickness: 4mm+9A+4mm

Glass Fabrication:  Moisture-proof aluminum strips+ Molecular sieve + Weather-resistant glue

Special Process Customized:  Full screen glass, half glass plus half plates, full plates, stainless steel wire mesh.

Separable Door Frame Cover: Width 83mm

Side Frame Thickness: 37mm

Upper Track Height: 37mm(sliding door)   67mm(top-hung sliding door)

Door Sash Width: 78mm

Door Sash Thickness: 40mm

Retractable Door Sleeve Cover: Thickness 83mm


图层 2.jpg

Product color


电泳香槟.png  白枫木.jpg  金橡木.jpg


晶泳樱桃木.png  澳洲红木.png
