83 Patented Casement Door Series
The integral design of door leaf and frame show stereoscopic impression, it is more in line with modern aesthetic concept.
Product Features
· The integral design of door leaf and frame show stereoscopic impression, it is more in line with modern aesthetic concept.
· The extrusions are full, homogenous thickness, the stress position is thickened and added with reinforced parts.
· It uses heat-transfer printing technology, which is complex and has vivid texture. Its decorative effect is stronger with more diverse collocation styles.
· The profile is designed with European standard hardware slot, connecting multiple locking points, achieving a good anti-theft effect.
· 12mm width of aluminum strips ensure the connection tightness and sound-insulation effect. It has multiple wind and waterproof designs with sound-proof, dust-proof and water-proof functions.
· It uses SUS304 stainless steel hinges which can load 100KG, works 100000 times without damage.
· 5mm double-layers fully sealed automobile grade safety glass, with chemical molecular sieves and argon inflated, double-layer sealing, sound insulation, heat insulation, light transmittance, it effectively prevents glass from fogging.
· It uses 45 degree seamless splicing process, built-in aluminum corner connector and reinforced steel sheet,
It is noise-insulated, dustproof, more stable and durable in structures.
product structure
Product parameters
【Door Frame】Into the wall hole: Joint width 64mm(single cover), 82mm(without cover)
【Glass Thickness】4mm+12A+4mm
【Glass Fabrication】Moisture-proof aluminum strips+ molecular sieve + weathering seal rubbers
【Special Process Customized】Full screen glass, half glass plus half plates, full plates, stainless steel wire mesh, manual blinds
【Front View of Door Frame】83mm (single or double covers), 51mm (without cover)
【Door Frame cover】32mm(single side) 46mm(double sides)
【Door Sash Width】83mm
【Door Sash Thickness】40mm
Product color
