SANGRUI 65 Thermal-break Casement Window Series

SANGRUI Door and Window System is a high-end door and window system independently developed by DIAOSI. It is a open-inward style and economical system with high performance and practicability. Its ingenious design can flexibly meet the needs of households with high demand.

< Previous
Next >
Back
Product Features


· SANGRUI Door and Window System is a high-end door and window system independently developed by DIAOSI. It is a open-inward style and economical system with high performance and practicability. Its ingenious design can flexibly meet the needs of households with high demand.

· It has the mechanical combined structure of three cavities, frame joint corners are punched seamlessly, extrusions structure by thermal-break injected glue. High strength assembly system can ensure that windows are more stable, firm and long life.

· It uses wide strips of TECHNOFORM brand, The thermal insulation effect is significant, and the thermal insulation bridge is on the same vertical line to maximize the thermal insulation

· The central rubber strips are designed based on the principle of rain curtain, it can realize three seals effect, with good airtight and watertight performance, and can cope with bad weather

· EPDM sealing strip is adopted to hold the glass firmly, to achieve isobaric sealing and air pressure balance in drainage position, It is a perfect sealing system.

· It effectively avoids the problems of fogging and water seepage, and can absorb the shock on glass.

The outside window is equipped with drip line design, which can effectively prevent rainwater from infiltrating into the window sash and cavity body, so as to achieve effective drainage function.

· The design, that combined wind cap can drain off water, and also have the function of dust-proof, wind pressure resistance and mosquito-proof, etc.

· It adopts German high-grade hardware fittings, the application of hidden and visible mounted hardware, which can resist wind pressure, prevent leakage and rain, and have good sound-proof effect. It can load 200 KG for each opening sash. It is a special hardware system for casement window outward, and can prevent the theft from prying window sash. The safety structure of anti-falling is equipped, can grasp the sash firmly even if it fell off.

· It adopts high quality manganese and magnesium alloy, high strength structure and bear the ultra wind pressure.

Thermal-break bridge structure and ensure the performance of energy-saving, firmness, durability, water-proof and wind resistance.

· The German imported handle, its outline is graceful, complying with the ergonomic design, the handle feels comfortable by the 12-layers surface treatment, it is often new, mute and durable.

· Window sash is surrounded by mechanical hardware and handles of multiple functions. When closed, each line of windows sash is fixed into the frames, so it has the excellent performance of safety and anti-theft.

· It is availably customized for aluminum profiles colors and window open style. Various of extrusions and glass

is optional. Double glazing is configured by 5+12A+5mm clear tempered glass. The blinds can be put inside for heat-insulation and day-lighting.


product structure


Glass sash.jpg

Product parameters


Production Materials:  Aluminum alloy, High strength manganese and magnesium alloy

Window Frames:    Into wall hole: Joint width 65mm, height: 54mm

Open Style: Open-outward, Open-inward, Tilt-turn inward, Awning, Top-hung outward

Glass Specification: 5mm+20A+5mm double tempered glass

                 Optional: 5mm+12A+5mm+12A+5mm triple tempered glass

Hardware: SIEGENIA (SI)


Product color


Outer color


氟碳香槟.jpg  咖啡色.png  氟碳铁灰.png


Inner color


缅甸泰柚.png  白枫木.jpg  金橡木.jpg

product style


图层 2.jpg

Product suggestion


Recommended Scope of Use:

High-class clubs, Star-rated hotels, Luxury villas, Large gardens and other large outdoor space.


Recommended Decorative Styles:

Luxury European style, Classic Chinese style, Fashion simple European style, Baroque style, Rural style.
